Blade shaped cartridge tip with 4.83 mm edge width and a tinned area extended to 5.84 mm. The larger wetted surface carries more solder and keeps heat flow steady while dragging along long pin rows. Tip length 16 mm, 325-358 °C.
Soldering tip blade 4.83 mm with enlarged tinned area - Thermaltronics TM60DS526
THERMALTRONICS
Original product
Net price (excl. VAT)
€24.29
Item
WL38429
Manufacturer no.
TM60DS526
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.TM60DS526
ConditionNew
Article
WL38429
Frequently Bought Together
-
This Item:
€24.29
-
Soldering tip conical 0.20 mm, micro fine, T series - Thermaltronics TM80C002
€18.61
-
Soldering tip chisel 1.0 mm short 6.4 mm T series - Thermaltronics TM60CH179
€13.25
Total price
Soldering long lead rows in one pass calls for a solder reservoir that is not empty after a few pins. This T series blade tip has a 4.83 mm edge, and the tinned area extends beyond it to 5.84 mm, so more solder is available per stroke.
Benefits
- Blade form 4.83 mm wide for drag soldering and clearing solder bridges
- Enlarged tinned area of 5.84 mm as a bigger solder reservoir per pass
- 16 mm tip length for a flat approach along the package edge
- Steady 325-358 °C through the Curie point control of the T series
- RoHS compliant and suited to lead-free alloys with higher heat demand
Technical data
| Item number | WL38429 |
| Model | TM60DS526 |
| Manufacturer | Thermaltronics |
| Manufacturer item number | TM60DS526 |
| Dimensions with packaging (LxWxH) | 117 mm x 33 mm x 13 mm |
| Dimensions with packaging in inches (LxWxH) | 4.6 in x 1.3 in x 0.5 in |
| Order unit | Piece |
| Product series | T tip series, 325-358 °C |
| Temperature range | 325-358 °C |
| Soldering or desoldering tip | Soldering tip |
| Tip length | 16 mm |
| Tip length in inches | 0.63 in |
| Tip width | 4.83 mm |
| Tip width in inches | 0.19 in |
| Tip shape | knife-shaped |
| Matching hand piece | SHP-T |
| Weight | 0.1 kg |
| Compliance | RoHS compliant, lead-free soldering |
Applications
For drag soldering fine pitch ICs, attaching ribbon terminations and shielding cans, and for wicking solder bridges off pin rows.
Compatibility and scope of delivery
Fits the SHP-T hand piece of the TMT-5000S-1 and TMT-5000S-2 soldering stations. Scope of delivery one soldering cartridge, order unit piece.
| Manufacturer Nr. | TM60DS526 |
|---|---|
| Manufacturer | Thermaltronics |
| Weight | 0.100000 |
| GPSR manufacturer information | AMS Ltd, Unit 3 Norse Trade Park, Congleton CW12 1GW, www.ams-electronics.co.uk |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
