Extraction cabinet with air curtain 200 m³/h, Easy-Click 60, 230 V - Weller CBCA112G04G65I2N

Working with fumes and dust at the bench calls for protection without blocking the view. The CBC-A extraction cabinet sits directly on the workbench and uses a double air curtain instead of a glass pane, so the large front opening remains fully accessible. Extraction demand is only 200 m³/h.

Benefits

• About 80 % lower energy cost than a conventional hood because 200 m³/h are needed instead of 1000 m³/h
• Double air curtain separates operator and application while the large front opening stays clear
• Interior lighting 2 x 39 W and 4 device sockets 230 V inside the cabinet
• Low noise emission of 49 dBA at 65 W connected load
• Mobile use on a work table or trolley, Easy-Click 60 connection

Technical data

Applications

Workstations with solder fume, adhesive or solvent vapours and dust where the operator has to be protected while keeping free access to the workpiece. Because it stands on the bench and needs little airflow, the cabinet also suits positions retrofitted in production, laboratory and rework areas.

Compatibility and scope of delivery

Supplied as the CBC-A 112 G04 extraction cabinet with four Easy-Click 60 connections, interior lighting and four device sockets. Operation requires two MG 100S extraction units with high gas filter volume or one ZS 6V, ordered separately. Minimum extraction volume required is 180 m³/h, maximum 230 m³/h. For 120 V mains the CBCA112G02G6512115 version is available.
