Hot gas and smoke rise thermally and are best captured above the source, not from the side. This round extraction hood with a 350 mm diameter uses exactly that buoyancy and connects to the Alsident System 100 via a 100 mm tube. The aluminium hood with full polyester paint also handles light dust loads.
Round hood 350 mm DN100 aluminium white - Alsident 1-10036-5
ALSIDENT Original product
Net price (excl. VAT)
€320.59
Item WL40753
Manufacturer no. 1-10036-5
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.1-10036-5
ConditionNew
Article
WL40753
Frequently Bought Together
- This Item: €320.59
- Alsident 50-3721-1-23-4. Extraction arm System 50 Flex 2 joints, 900 mm, red - table mounting €395.09
- Alsident 50-8747-3-4. Extraction arm system DN50 3 joints, 1380 mm, red - ceiling mounting €439.12
Total price
Above ovens, solder baths, hot plates and any process with rising hot gas, a round hood works most effectively because it takes up the thermal plume directly. This 350 mm round hood belongs to the Alsident DN100 range and is designed for hot gas, smoke and light dust quantities.
Benefits
- Hood size of 350 mm for wide capture above the source
- Recommended for hot gas, smoke and light dust quantities
- Aluminium hood with full polyester paint, dimensionally stable under heat load
- Anodised aluminium pipe socket with 10μ layer thickness
- Polypropylene flange, direct connection to DN100 extraction arms
Technical data
| Item number | WL40753 |
| Model | 1-10036-5 |
| Manufacturer | Alsident |
| Manufacturer item number | 1-10036-5 |
| Hood size | 350 mm |
| Tube diameter | 100 mm |
| Colour | white |
| Material | Aluminium hood with full polyester paint, anodised aluminium pipe socket with 10μ layer thickness, polypropylene (PP) flange |
| Order unit | piece |
Applications
Typical positions are reflow and drying ovens, solder and tin baths, laboratory hot plates and stirrers, and filling or mixing operations with light dust release where the hood can sit closely above the source.
Compatibility and scope of delivery
Fits Alsident System 100 extraction arms with a 100 mm tube diameter. One round hood is supplied per order unit, without the extraction arm.
| Manufacturer Nr. | 1-10036-5 |
|---|---|
| Manufacturer | Alsident |
| Weight | 0.100000 |
| Colour | Silver |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
