Power supply with screw counter DC 40/32/24 V, 9 A for brushless electric screwdrivers - Kilews SKP-BC40HL-800 V4.0

A missing screw on the line is often only found at final inspection. The SKP-BC40HL-800 powers the screwdriver and counts at the same time: once the target of 1 to 99 screws is reached it outputs OK, otherwise NG, both as signals for the PLC.

The 800 version supplies 9 A and therefore also powers the high-torque SKD-RBK, SKD-LRBK and SKD-BK900 series.

Key benefits

• Screw counter 1 to 99, count-up or count-down, with OK, NG and OK ALL outputs
• Output DC 40, 32 or 24 V at 9 A, one unit from SKD-BN200 to SKD-RBK
• Soft start 0 to 9.9 s and start speed in nine levels from 30 to 90 %
• Running time monitoring with auto-learning detects tightening cycles that are too short or too long
• External inputs for start, reverse, disable, confirm, sensor and clear
• Memory for 5 data sets, selectable self-locking on counting errors

Applications

Process-controlled assembly on lines with PLC connection, checking the screw count per assembly, tracing NG parts and cycle-time workstations with sensor monitoring.

Compatibility and scope of delivery

Fits the Kilews SKD-BN200, SKD-BN500, SKD-BN800, SKD-BK900, SKD-RBK, SKD-LRBK, SKD-TBK30LF, 35LF, 50LF and 70L and SKD-TBN series. Scope of delivery: unit, power cord and 2 keys.

Standards and conformity

ETL, CE, RoHS.
