Conical bent soldering tip 0.7 mm for micro tweezers - JBC C120-004
Soldering tip from the JBC C120 series, conical bent, diameter 0.7 mm, for chip components. For the PA120 and AM120 micro tweezers, integrated heater, supplied singly.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
For soldering and desoldering chip components and dual-in-line parts with the JBC PA120 and AM120 micro tweezers, the C120004 provides a conical bent tip (diameter 0.7 mm) with an integrated heater.
Benefits
- Tip shape conical bent, diameter 0.7 mm, for chip components
- Heater integrated in the tip for fast, precise heat delivery to the smallest components
- Used in pairs in the PA120 and AM120 micro tweezers to heat both joints simultaneously
- Supplied singly, tool-free change
Applications
Soldering and desoldering chip components and dual-in-line ICs in SMD rework and prototyping.
Compatibility and scope of delivery
Fits the PA120-A and AM120-A micro desoldering tweezers. Supplied as a single tip (C120004); two tips are needed for tweezer operation.
Genuine JBC part, made in Spain. ESD-safe to IEC 61340-5-1, CE and RoHS compliant.
Technical data
| Item number | WL41661 |
|---|---|
| Model | C120-004 |
| Manufacturer | JBC |
| Manufacturer item number | C120004 |
| Product series | C120 |
| Tip series | C120 |
| Tip shape | conical bent |
| Tip dimensions | diameter 0.7 mm |
| Tip application | for chip components |
| Integrated heater | yes |
| Suitable handpiece | PA120, AM120 |
| Order unit | piece (single) |
| Weight | 0.1 kg |
| Manufacturer Nr. | C120004 |
| HS-Code | 85159080 |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Spain |
| ESD version | ESD (antistatic) |
| Certification | IEC 61340-5-1 |
| Soldering tip shape | konisch |
| Series | C120 |
