Bag filter cassette F9 prefilter 4x DN50 for ASD 300 and LAS 300 - ULT 02.1.454
Prefilter stage for ULT extraction units of the 300 series. The F9-01 bag filter cassette captures coarse dust and solder fume particles before they reach the downstream particulate filter, noticeably extending its service life. Four connection ports with 50 mm diameter accept up to four extraction points.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
When the expensive main filter of a solder fume extraction unit clogs too quickly, an effective prefilter stage is usually missing. The ULT F9-01 bag filter cassette takes on exactly this task in the 300 series extraction units and binds coarse dust and most of the particle load before the particulate filter.
Benefits
- Filter class F9 prefilter that relieves the downstream particulate filter and lowers operating costs
- Four DN50 ports for up to four extraction points running at the same time
- Bag design with a large effective filter area and correspondingly long service life
- Replaced as a complete cassette without tools and without removing the main filter
- Genuine ULT spare part for ASD 300 and LAS 300, fits without modification
Applications
The cassette is used in electronics manufacturing and repair workshops wherever several hand soldering or rework stations are connected to a central 300 series extraction unit. It also works as a protective stage during bonding and dispensing operations that generate particles.
Compatibility and scope of delivery
Suitable for the ULT extraction units ASD 300 and LAS 300. Supplied as one F9-01 bag filter cassette with four DN50 ports. Replacement intervals depend on the filter loading indicator of the unit and the actual dust load.
Technical data
| Item number | WL41847 |
|---|---|
| Model | 02.1.454 |
| Manufacturer | ULT |
| Manufacturer item number | 02.1.454 |
| Order unit | piece |
| Filter type | prefilter |
| Filter class | F9 |
| Connection diameter | 50 mm |
| Number of connections | 4 |
| Device series | ASD 300, LAS 300 |
| Weight | 0.100000 |
| Manufacturer Nr. | 02.1.454 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Nennweite DN [mm] | 50 |
| Norm | ISO 16890 |
