LED arm-mounted luminaire ROCIA.focus RFD 600/850/DS, 8 W, 10° spot - Waldmann 113182000-00680110

On machine tools and woodworking machines the light directly above the work point decides the result. The arm-mounted luminaire ROCIA.focus RFD 600/850/DS concentrates 600 lm through a 10° optic and delivers up to 30,053 lx at a distance of 50 cm.

Benefits in use

• The 10° optic concentrates 600 lm into a narrow cone, at a distance of 50 cm an average of 5,088 lx and a maximum of 30,053 lx are available.
• 8 W power consumption for 600 lm results in around 75 lm/W, which keeps running costs low in continuous operation.
• Connection is made to 12-28 V AC or 12-40 V DC machine voltage without an additional operating device, the approx. 3 m cable ends in free stranded wires.
• Degree of protection IP67 and the Viton seal keep oils and cooling lubricants out of the housing, the cover is 3 mm thick safety glass.
• Switchable and continuously dimmable by pushbutton, the pivoting head and the spring-balanced arm hold the position that has been set.
• Maintenance-free LED technology with an L70 service life of more than 60,000 h, approved up to an ambient temperature of Ta max 40 °C.

Areas of application

• machine tools
• woodworking machines
• assembly and placement workstations in production
• pinpoint illumination of individual work and inspection points
