Round hood DN100 Ø500 mm in transparent PETG, System 100 AL - Alsident 1-10050-5
Above open containers and wide work areas a large round hood captures light fumes and gases better than a point extraction tip. This Ø500 mm hood is made of transparent PETG with an anodised aluminium tube socket and keeps the work in view. The reinforced rim makes repositioning during work more stable.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Light vapours and gases rise and are captured most effectively by a large-area hood, provided the view of the workpiece is not lost. The Alsident 1-10050-5 is a Ø500 mm round hood for System 100 AL, made from transparent PETG.
Benefits
- Ø500 mm hood size, recommended for capturing light fumes and gases
- Transparent PETG, resistant to solvents and most cleaning agents, can also be cleaned with alcohol
- Clear view of the workpiece despite the large capture area
- Edge reinforcement for greater stability when handling the hood
- Anodised aluminium tube socket with 10 µm layer thickness
- Higher capture performance when the hood is placed vertically or at an angle
Applications
Capture of light gases and vapours above open containers, at bonding and coating stations, in laboratories and over wider worktops where an extraction tip would cover too small an area. Efficiency increases with the hood set at an angle.
Compatibility and scope of delivery
For extraction arms of the Alsident System 100 AL in nominal size DN100, intended for general use without special requirements for dissipative properties or chemical resistance. Delivery comprises the round hood with tube socket. The protective grille is available as an accessory.
Technical data
| Item number | WL46461 |
|---|---|
| Model | 1-10050-5 |
| Manufacturer | Alsident |
| Manufacturer item number | 1-10050-5 |
| Product series | Alsident System 100 AL |
| Design | Round hood |
| Hood size | Ø500 mm |
| Nominal size | DN100 |
| Hood material | Transparent PETG |
| Tube socket material | Anodised aluminium, layer thickness 10 µm |
| Colour | silver / transparent, plastic parts white (-5) |
| Order unit | piece |
| Weight | 0.100000 |
| Manufacturer Nr. | 1-10050-5 |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Condition of article | New |
| Article authenticity | Original product |
| Colour | Silver |
