Extraction tip DN75 250 mm with cantilevered nozzle, PP mouth red - Alsident 1-7526-4
Point sources such as a solder joint or a bonding seam are captured most effectively right where they arise. This 250 mm extraction tip in nominal size DN75 reaches close to the source thanks to its cantilevered nozzle, without getting in the way of the hand. The tube is anodised aluminium, the mouth chemically resistant polypropylene in red.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
On small, concentrated sources a large hood achieves little because the capture flow is spread over the whole area. The Alsident 1-7526-4 is a 250 mm extraction tip for DN75 extraction arms, brought close to the solder joint or bonding seam.
Benefits
- Designed for concentrated sources of contamination, high capture efficiency through proximity to the source
- The cantilevered tip raises capture performance further
- Positioned directly at the source without hindering the work process
- Anodised aluminium tube with 10 µm layer thickness
- Mouth in impact-resistant, chemically resistant polypropylene (PP), clearly visible in red
Applications
Capture of solder fumes at hand soldering and rework benches, of vapours at bonding and dispensing points and of process gases at small, locally confined sources in electronics manufacturing, laboratories and workshops.
Compatibility and scope of delivery
For Alsident system extraction arms in nominal size DN75. Delivery comprises the extraction tip with tube and mouth.
Technical data
| Item number | WL47127 |
|---|---|
| Model | 1-7526-4 |
| Manufacturer | Alsident |
| Manufacturer item number | 1-7526-4 |
| Design | Extraction tip with cantilevered nozzle |
| Nominal size | DN75 |
| Length | 250 mm |
| Tube material | Anodised aluminium, layer thickness 10 µm |
| Mouth material | Polypropylene (PP) |
| Mouth colour | red (-4) |
| Order unit | piece |
| Weight | 0.100000 |
| Manufacturer Nr. | 1-7526-4 |
| GPSR manufacturer information | Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com |
| Condition of article | New |
| Article authenticity | Original product |
| Colour | Red |
Downloads
Datasheet
Catalogue
- Alsident System 100 extraction arms DE
- Alsident System 25 extraction arms DE
- Alsident System 50 extraction arms DE
- Alsident System 63 extraction arms DE
- Alsident System 75 extraction arms DE
- Alsident extraction arms and capture elements, short overview DE
- Flextractor extraction arms and capture elements DE
