Hose set 6 m with extraction arm 650 mm and nozzle, 50 to 75 mm - Donaldson Bofa A1020480

When the extraction unit does not stand right next to the bench, a short standard hose is not enough. This BOFA set provides 6 m of ducting in 50 to 75 mm nominal diameter together with a 650 mm extraction arm and matching nozzle, so the capture point is connected cleanly even over a longer distance.

Benefits

• 6 m hose length for extraction units positioned away from the workstation
• Extraction arm of 650 mm holds the nozzle rigidly over the soldering joint
• Nominal diameter 50 to 75 mm for connection to units and capture points of different sizes
• Nozzle included in the set, no separate purchase of capture elements needed
• Matched transitions avoid false air and pressure loss in the duct run

Technical data

Applications

Connecting soldering benches, rework stations, bonding and dispensing stations to a centrally or remotely placed BOFA extraction unit. Equally suitable for laser marking cells where the capture point is positioned on an arm.

Compatibility and scope of delivery

For BOFA extraction units with connections in 50 mm and 75 mm nominal diameter. Scope of delivery: 6 m hose run, 650 mm extraction arm and extraction nozzle. Further accessories such as reducers and additional nozzles are available separately from the BOFA range.
