LED surface-mounted luminaire MACH LED PLUS.forty MLAL 27 S, 365 mm, 10.5 W, 1080 lm - Waldmann 113162000-00662685

Where a machine tool offers little installation space, the MACH LED PLUS.forty MLAL 27 S delivers 1080 lm at 10.5 W power consumption over a length of 365 mm and a housing diameter of 40 mm. A single luminaire is enough to light a smaller working area to standard, without reserving extra space for the fixture.

What the luminaire delivers in operation

• 365 mm length at 40 mm housing diameter, so it fits between cladding and working area
• Reflector with a 90 degree angle of illumination for wide and even coverage of the work surface
• Degree of protection IP67, watertight and oiltight and therefore resistant to cooling lubricant and splash water
• Vibration resistant from 10 to 55 Hz at 0.35 mm amplitude, shock proof up to 50 g
• LED service life L70 above 60 000 h, which keeps maintenance intervals long
• Colourless anodised aluminium housing with 4 mm thick safety glass and Viton seals
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Applications

• Working area lighting in machine tools and machining centres
• Production cells and automation systems with restricted installation space
• Areas with cooling lubricant, oil and splash water thanks to IP67
• Machines with vibration loads up to 55 Hz

Connection and mounting

The luminaire is connected with 20-28 V DC through an A-coded M12 plug-in connector. It works without a built-in operating device, for operation on mains voltage Waldmann offers 24 V DC constant voltage units as accessories. Mounting is done with luminaire brackets from the accessory range, at least two brackets are required per luminaire.

Made in Germany. The luminaire is designed to be repairable.
