The R470017 is a chisel-shaped R470 series soldering tip with a 4 x 1.8 mm blade and 15° angle for automated soldering processes. Its square cross-section centres the tip exactly in the iron and lets it be set in four positions in 90° steps. It fits the TR470 and TRA470 soldering irons.
Soldering tip R470 chisel 4x1.8 mm 15° for TR470 - JBC R470017
JBC
Original product
Net price (excl. VAT)
€48.02
Item
WL54745
Manufacturer no.
R470017
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R470017
ConditionNew
Article
WL54745
The R470017 is a chisel-shaped R470 series soldering tip for automated soldering processes. Its square cross-section centres it perfectly in the soldering iron and ensures precise vertical positioning.
Benefits
- For automated soldering processes with repeatable positioning
- Square cross-section centres the tip exactly in the iron
- Usable in four positions, changed in 90° steps
- Chisel form 4 x 1.8 mm with 15° angle for general use
Technical data
| Item no. | WL54745 |
| Manufacturer item no. | R470017 |
| Manufacturer | JBC |
| Product series | R470 |
| Tip shape | chisel-shaped |
| Tip dimensions | 4 x 1.8 mm |
| Tip length | 16.9 mm |
| Tip width | 4 mm |
| Tip thickness | 1.8 mm |
| Angle | 15° |
| Alignment | straight |
| Use | general |
| Suitable handpiece | TR470, TRA470 |
| Suitable stand | CS2R470 |
| Order unit | piece |
Applications
General soldering in automated robotic soldering processes with the TR470 and TRA470 handpieces.
Compatibility and scope of delivery
Suitable for the TR470 and TRA470 soldering irons and the CS2R470 stand. Supplied as a single piece.
Made in Spain.
| Manufacturer Nr. | R470017 |
|---|---|
| Manufacturer | JBC |
| Weight | 0.100000 |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Article authenticity | Original product |
| Condition of article | New |
| Series | R470 |
| Tip diameter/width [mm] | 4.000000 |
| Soldering tip shape | meißelförmig |
