KL300 LED cold light source 5600 K with wide range power supply - Leica 31120300

Light at a microscope station has to be bright enough for small structures without heating the specimen. The KL300 LED reaches the brightness of a 30 watt halogen cold light source, does so with an LED and is cooled by convection, which means no fan inside the housing.

Key benefits

• Colour temperature of around 5600 K, a neutral white light close to daylight that lets solder joints and markings be judged properly.
• Continuous dimming from 0 to 100 percent, so reflections on bare metal can be reduced without switching the source off.
• Separate on and off switch next to the dimmer.
• Wide range power supply from 100 to 240 V and 50 to 60 Hz, the same light source runs at any site.
• Convection cooling in a compact housing, no fan noise at the inspection station.

Applications

Illumination of stereo microscopes in assembly inspection and rework, incident light through a gooseneck or a ring light and transmitted light through a base with a light guide port, as well as laboratory and specimen work.

Compatibility and scope of delivery

Cold light source and wide range power supply are supplied per sales unit. Light guides and ring lights are not included and are ordered separately. The datasheet at hand states neither weight nor housing dimensions.
