PCB magazine 601.3, low height, metal side walls, 28 slots, 320 x 355 x 343 mm - cab 8916130
PCB magazine from the cab 600 series with a reduced height of 343 mm and 28 slots, e.g. for curing ovens. Metal side walls, guides and ambient up to 200 °C, width set by screw clamping.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Curing ovens offer limited usable height, and heavy PCBs or carriers quickly overload a full magazine. This 600 series version is reduced to 343 mm height and holds PCBs in 28 slots, with metal side walls withstanding up to 200 °C.
Benefits
- Low height of 343 mm, suitable for curing ovens
- Reduced height prevents weight overload with heavy PCBs or carriers
- Metal side walls, guides and ambient up to 200 °C
- Width adjustment via screw clamping
Applications
Curing and tempering of assemblies, storage of heavy PCBs and carriers in SMT production.
Technical data
| Manufacturer | cab |
|---|---|
| Model | 601.3 |
| Manufacturer part number | 8916130 |
| Series | 600 |
| Side wall material | metal |
| External dimensions W x D x H | 320 x 355 x 343 mm |
| Slots | 28 |
| Max. temperature of guides | 200 °C |
| Max. ambient temperature | 200 °C |
| Width adjustment | screw clamping |
| Weight | 5.5 kg |
| Manufacturer Nr. | 8916130 |
| HS-Code | 73269040 |
| GPSR manufacturer information | cab Produkttechnik GmbH & Co. KG, Wilhelm-Schickard-Str. 14, DE-76131 Karlsruhe, www.cab.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
