ESD PCB magazine 601.2, polycarbonate side walls, PCB width 40-250 mm, 320 x 355 x 563 mm - cab 8916601

Populated and bare PCBs have to be buffered, transported and handed over to SMT lines safely between production steps. This magazine holds PCBs 40-250 mm wide and up to 342 mm long, with guides withstanding up to 130 °C. On the 600 series, the side wall is set to the PCB width via four screw clamps - the cost-effective variant for lines with rarely changing formats.

Benefits

• PCB width continuously adjustable, 40-250 mm
• Width adjustment: screw clamping
• Transport lock on front and rear: a latch locks the guides during transport
• ESD-safe, surface resistance according to DIN EN 61340-5-1
• Supplied partly assembled, assembled version available under a separate part number

Applications

SMT production, reflow and wave soldering lines, storage and transport of assemblies between production steps.
