PCB magazine with parallel slots 603.3-P, PCB width 40-130 mm, 380 x 400 x 563 mm - cab 8916395

cab ✓ Original product Brand new Made in Germany

PCB magazine with parallel slots from the cab 600 series for PCBs 40-130 mm wide and up to 387 mm long. Guides rated up to 200 °C. External dimensions 380 x 400 x 563 mm, stackable, with transport lock.

Net
€1,074.84
excl. VAT
Item WL60360
Manufacturer no. 8916395
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Populated and bare PCBs have to be buffered, transported and handed over to SMT lines safely between production steps. This magazine holds PCBs 40-130 mm wide and up to 387 mm long, with guides withstanding up to 200 °C. For narrow PCBs two slot rows are available side by side, which doubles the magazine capacity.

Benefits

  • PCB width continuously adjustable, 40-130 mm
  • Transport lock on front and rear: a latch locks the guides during transport
  • Metal side walls for high mechanical and thermal loads

Applications

SMT production, reflow and wave soldering lines, storage and transport of assemblies between production steps.

Technical data

Manufacturercab
Model603.3-P
Manufacturer part number8916395
Series600
PCB width40-130 mm
Max. PCB length387 mm
External dimensions W x D x H380 x 400 x 563 mm
Slots2
Max. temperature of guides200 °C
Max. ambient temperature200 °C
Weight0.1 kg
Manufacturer Nr.8916395
HS-Code73269040
GPSR manufacturer informationcab Produkttechnik GmbH & Co. KG, Wilhelm-Schickard-Str. 14, DE-76131 Karlsruhe, www.cab.de
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
