ESD PCB magazine with parallel slots 603.2-P, PCB width 40-130 mm, 380 x 400 x 563 mm - cab 8916425
ESD PCB magazine with parallel slots from the cab 600 series for PCBs 40-130 mm wide and up to 387 mm long. Guides rated up to 130 °C. External dimensions 380 x 400 x 563 mm, stackable, with transport lock.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Populated and bare PCBs have to be buffered, transported and handed over to SMT lines safely between production steps. This magazine holds PCBs 40-130 mm wide and up to 387 mm long, with guides withstanding up to 130 °C. For narrow PCBs two slot rows are available side by side, which doubles the magazine capacity.
Benefits
- PCB width continuously adjustable, 40-130 mm
- Transport lock on front and rear: a latch locks the guides during transport
- ESD-safe, surface resistance according to DIN EN 61340-5-1
- Stackable or suitable for turning operation
Applications
SMT production, reflow and wave soldering lines, storage and transport of assemblies between production steps.
Technical data
| Manufacturer | cab |
|---|---|
| Model | 603.2-P |
| Manufacturer part number | 8916425 |
| Series | 600 |
| PCB width | 40-130 mm |
| Max. PCB length | 387 mm |
| External dimensions W x D x H | 380 x 400 x 563 mm |
| Slots | 2 |
| Max. temperature of guides | 130 °C |
| Max. ambient temperature | 100 °C |
| ESD-safe | yes |
| Weight | 7 kg |
| Manufacturer Nr. | 8916425 |
| HS-Code | 39239000 |
| GPSR manufacturer information | cab Produkttechnik GmbH & Co. KG, Wilhelm-Schickard-Str. 14, DE-76131 Karlsruhe, www.cab.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | ESD (antistatic) |
