Depaneler MAESTRO 4S, aluminium set-up, motorised, separation length 600 mm - cab 8936745.520
cab MAESTRO 4S depaneler for separating pre-scored PCB panels, separation length 600 mm. Component side circular blade, solder side linear blade, motor driven separation, components up to 34 mm high.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Breaking pre-scored PCB panels by hand stresses solder joints and components close to the V-groove. The MAESTRO 4S separates them in a controlled way along the groove, with a circular blade on the component side and a linear blade on the solder side, over a separation length of 600 mm. The blade gap is entered on the control panel and set by motor; passing the groove several times with readjusted blade gap considerably reduces stress on sensitive components.
Benefits
- Separation length 600 mm
- Separation principle: circular blade on component side, linear blade on solder side
- Component height up to 34 mm on component side, up to 34 mm on solder side
- 9 storable programs, cutting performance display for preventive maintenance
- Separation speed 300. 500 mm/s, switchable
- Approvals CE, FCC Class A
- Path-optimised motor drive with 9 storable programs of 1 - 5 separating steps each
Applications
Electronics production and assembly: separating pre-scored FR4 PCB panels after placement and soldering.
Technical data
| Manufacturer | cab |
|---|---|
| Model | MAESTRO 4S Alu set-up |
| Manufacturer part number | 8936745.520 |
| Separation principle | component side circular blade, solder side linear blade |
| Separation process | motor driven |
| Separation length | 600 mm |
| Separation speed | 300. 500 mm/s |
| Component height | component side up to 34 mm, solder side up to 34 mm |
| Blade gap | 0.9 - 0.05 mm |
| Programs | 9 |
| Voltage | 100-240 VAC, 50/60 Hz |
| PCB material | FR4 |
| External dimensions W x D x H | 852 x 434 x 425 mm |
| Weight | 46 kg |
| Approvals | CE, FCC Class A |
| Separating speed | 300, 500 mm/s, switchable |
| Depositing table depth | 200 mm |
| Sound pressure level | LpA < 70 dB(A) |
| Operating conditions | +10 - 35 °C / 10 - 85 % RH, non-condensing |
| Manufacturer Nr. | 8936745520 |
| HS-Code | 84659900 |
| GPSR manufacturer information | cab Produkttechnik GmbH & Co. KG, Wilhelm-Schickard-Str. 14, DE-76131 Karlsruhe, www.cab.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
