ESD/EMI shielding bag DRY-PACK, moisture barrier, 90 µm, 254 x 508 mm, pack of 100 - Safeguard 20-082-1020

Name: ESD/EMI shielding bag DRY-PACK, moisture barrier, 90 µm, 254 x 508 mm, pack of 100 - Safeguard 20-082-1020
Brand: Safeguard
SKU: WL60861
Price: 83.53 EUR
Availability: InStock

Safeguard ✓ Original product Brand new Made in France

Multi-layer ESD/EMI shielding bag DRY-PACK in 254 x 508 mm for moisture-sensitive devices. Water vapour transmission is at most 0.0003 g/100 in²/24 h and electrostatic shielding below 10 nJ. Heat sealable and vacuum sealable, made to MIL-PRF-81705D Type 1.

Net

€83.53

excl. VAT

Item WL60861

Manufacturer no. 20-082-1020

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Moisture-sensitive devices such as BGAs or QFNs must stay dry until they reach the placement line. Safeguard DRY-PACK bag 20-082-1020 combines a moisture barrier with an MVTR of no more than 0.0003 g/100 in²/24 h and ESD/EMI shielding below 10 nJ. At 254 x 508 mm it takes reels, trays and assemblies.

Key benefits

Moisture barrier: water vapour transmission rate (MVTR) ≤ 0.0003 g/100 in²/24 h.
Shielding against electrostatic discharge and fields: < 10 nJ.
Fast dissipation: decay from 1000 V to 100 V in under 0.02 s, typical surface resistance 1 x 10¹¹ ohms.
Heat sealable and vacuum sealable for dry packing with desiccant and humidity indicator.
Marked with ESD/EMI symbol, moisture symbol, type designation, recycling symbol and lot number.

Applications

Dry packing of moisture-sensitive devices (MSD), long-term storage of reels and trays, shipping assemblies to humid climates.

Standards

Complies with MIL-PRF-81705D Type 1 and EIA-583. ESD certification to IEC 61340-5-1.

Technical data

Size (W x H)	254 x 508 mm
Film thickness	90 µm
Colour	silver
Construction	multi-layer
Electrostatic shielding	< 10 nJ
Typical surface resistance (Rpp)	1 x 10¹¹ ohms
Decay time 1000 V to 100 V	< 0.02 s
Water vapour transmission (MVTR)	≤ 0.0003 g/100 in²/24 h
Packaging property	vacuum sealable, heat sealable
Zip closure	no
Resealable	no
Specification	MIL-PRF-81705D Type 1, EIA-583
ESD certification to IEC 61340-5-1	yes
Sales unit	pack of 100
Weight	0.04 kg
Manufacturer	Safeguard
Manufacturer Nr.	20-082-1020
HS-Code	39232990
GPSR manufacturer information	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Condition of article	New
Article authenticity	Original product
Country of Manufacture	France
ESD version	ESD (antistatic)
