PreciStrip16 automatic insulation stripper 0.08 - 16 mm2, 195 mm, sales packaging - Knipex 12 52 195 SB
The PreciStrip16 strips round cables from finely stranded to solid, 0.08 to 16 mm2, with a single tool. Semicircular metal holding jaws with a comb profile provide grip, parabolic stripping blades make the cut exact, and an automatic system controls the cutting depth whose zero point can be adjusted in fine steps. This version comes in the self-service sales packaging.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Working from a thin control core up to a solid 16 mm2 conductor with a single tool, and without nicking the conductor, is what the PreciStrip16 is built for. It covers the range from 0.08 to 16 mm2 and an automatic system controls the cutting depth of the stripping blades. Its zero point can be adjusted in fine steps for special conditions such as unusual insulating material or temperature. This version is supplied in the self-service sales packaging for display racks.
Advantages
- Simple, precise stripping of round cables from finely stranded to solid across the wide range of 0.08 to 16 mm2 with one tool only.
- Good grip from semicircular metal holding jaws with a comb profile, exact cut from parabolic stripping blades.
- Automatic control of the cutting depth, zero point finely adjustable for special operating conditions.
- Adjustable length stop for precise, repeatable work in series.
- Cable cutter on top for copper and aluminium conductors, finely stranded up to 16 mm2 (AWG 6) and solid up to 6 mm2 (AWG 10).
- Easily exchangeable blade cassette, with the blade block 12 49 32 available as an option for very hard halogen-free cables from 4 to 16 mm2.
- Ergonomic two-component handle, marking field for individual labelling and a fastening eyelet for KNIPEX Tethered Tools accessories.
Areas of use
Electrical installation, control cabinet and switchgear building, industrial assembly and maintenance, including work at height thanks to the fastening eyelet.
Technical data
| Type | KNIPEX PreciStrip16, automatic insulation stripper |
|---|---|
| Stripping range | 0.08 - 16 mm2, finely stranded to solid, round cable |
| Cable cutter | on top, copper and aluminium, finely stranded up to 16 mm2 (AWG 6), solid up to 6 mm2 (AWG 10) |
| Holding jaws | semicircular, metal, with comb profile |
| Stripping blades | parabolic, blade cassette easily exchangeable |
| Setting | automatic cutting depth, zero point finely adjustable, adjustable length stop |
| Length | 195 mm |
| Handle | ergonomic two-component handle with marking field |
| Drop protection | with fastening eyelet, suitable for KNIPEX Tethered Tools accessories |
| Optional accessory | blade block 12 49 32 for very hard halogen-free cables 4 - 16 mm2 |
| Packaging | sales packaging, self-service blister |
| Weight | 0.23 kg |
| Manufacturer | Knipex |
| Manufacturer Nr. | 12 52 195 SB |
| HS-Code | 82032000 |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Overall length [mm] | 195 |
