End cutting nippers 200 mm for binding wire, black atramentised, hard wire up to Ø 2.8 mm - Knipex 68 01 200

Knipex ✓ Original product Brand new

End cutting nippers with front cutting edges for twisting and cutting binding wire. They cut soft wire up to Ø 4.0 mm, medium hard wire up to Ø 3.5 mm and hard wire up to Ø 2.8 mm at approx. 61 HRC edge hardness. Overall length 200 mm, weight 319 g.

Net
€16.74
excl. VAT
Item WL61631
Manufacturer no. 68 01 200
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Binding wire has to be cut close to the knot, otherwise sharp ends are left behind. These end cutting nippers carry the cutting edges at the front of the head and cut hard wire up to Ø 2.8 mm and soft wire up to Ø 4.0 mm. Overall length is 200 mm.

Benefits

  • Twists and cuts binding wire in one working step, the front cutting edges reach right up to the knot
  • The head shape supports the movement sequence when tightening mesh knots in reinforced concrete work
  • Cutting capacity Ø 4.0 mm in soft wire, Ø 3.5 mm in medium hard wire and Ø 2.8 mm in hard wire
  • Cutting edges additionally hardened to approx. 61 HRC, which keeps the edges sharp over a long service life
  • Cutting edge length 31 mm on 200 mm overall length, plastic coated handles
  • Polished head, made to DIN ISO 5748

Applications

Reinforcement and rebar tying work on site, fencing and wire mesh, metalworking and general workshop use. Wherever wire has to be cut close to the joint.

Standards and compliance

The pliers are made to DIN ISO 5748. According to the manufacturer they contain no substances of very high concern under REACH. The RoHS directive is not applicable to this hand tool.

Technical data

EAN4003773013815
Pliersblack atramentised
Headpolished
Handlesplastic coated
Weight319 g
Dimensions200 x 50 x 32 mm
StandardDIN ISO 5748
REACH compliancecontains no SVHC
RoHS compliancenot applicable
Cutting capacity soft wireØ 4.0 mm
Cutting capacity medium hard wireØ 3.5 mm
Cutting capacity hard wireØ 2.8 mm
Cutting edge length31 mm
Weight0.319000
ManufacturerKnipex
Manufacturer Nr.68 01 200
GPSR manufacturer informationKNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de
Condition of articleNew
Article authenticityOriginal product
Height32 mm
Width50 mm
ColourBlack
Farbeschwarz
NormDIN ISO 5748
Overall length [mm]200.000000

Downloads

Accessories

Videos

Verdrillen. Spannen. Schneiden. KNIPEX Vornschneider 68 01 200.
