End cutting nippers with front cutting edges for twisting and cutting binding wire. They cut soft wire up to Ø 4.5 mm, medium hard wire up to Ø 4.0 mm and hard wire up to Ø 3.2 mm at approx. 61 HRC edge hardness. Overall length 280 mm, weight 465 g.

End cutting nippers 280 mm for binding wire, black atramentised, hard wire up to Ø 3.2 mm - Knipex 68 01 280

KNIPEX Original product
Net price (excl. VAT)
€19.48
Item WL61632
Manufacturer no. 68 01 280
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.68 01 280
EAN4003773077664
ConditionNew
Article
WL61632

Binding wire has to be cut close to the knot, otherwise sharp ends are left behind. These end cutting nippers carry the cutting edges at the front of the head and cut hard wire up to Ø 3.2 mm and soft wire up to Ø 4.5 mm. Overall length is 280 mm.

Benefits

  • Twists and cuts binding wire in one working step, the front cutting edges reach right up to the knot
  • The head shape supports the movement sequence when tightening mesh knots in reinforced concrete work
  • Cutting capacity Ø 4.5 mm in soft wire, Ø 4.0 mm in medium hard wire and Ø 3.2 mm in hard wire
  • Cutting edges additionally hardened to approx. 61 HRC, which keeps the edges sharp over a long service life
  • Cutting edge length 33 mm on 280 mm overall length, plastic coated handles
  • Polished head, made to DIN ISO 5748

Technical data

EAN4003773077664
Pliersblack atramentised
Headpolished
Handlesplastic coated
Weight465 g
Dimensions280 x 50 x 32 mm
StandardDIN ISO 5748
REACH compliancecontains no SVHC
RoHS compliancenot applicable
Cutting capacity soft wireØ 4.5 mm
Cutting capacity medium hard wireØ 4.0 mm
Cutting capacity hard wireØ 3.2 mm
Cutting edge length33 mm

Applications

Reinforcement and rebar tying work on site, fencing and wire mesh, metalworking and general workshop use. Wherever wire has to be cut close to the joint.

Standards and compliance

The pliers are made to DIN ISO 5748. According to the manufacturer they contain no substances of very high concern under REACH. The RoHS directive is not applicable to this hand tool.

More Information
Weight 0.465000
Manufacturer Knipex
Manufacturer Nr. 68 01 280
EAN 4003773077664
GPSR manufacturer information KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de
Condition of article New
Article authenticity Original product
Height 32 mm
Width 50 mm
Colour Black
Farbe schwarz
Norm DIN ISO 5748
Overall length [mm] 280.000000
