High leverage diagonal cutter, 200 mm long, with comfort handles made of three ergonomic components. The induction-hardened edges of approx. 64 HRC cut medium-hard wire up to 4.2 mm, hard wire up to 3.0 mm and piano wire up to 2.5 mm. Two KNIPEXtend interfaces take extensions, weight 300 g.
High leverage diagonal cutter with comfort handles and KNIPEXtend interfaces, 200 mm - Knipex 74 22 200
KNIPEX
Original product
Net price (excl. VAT)
€29.19
Item
WL61710
Manufacturer no.
74 22 200
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.74 22 200
EAN4003773051831
ConditionNew
Article
WL61710
Frequently Bought Together
-
This Item:
€29.19
-
Bahco 2101S-160. Ergo Diagonal cutters with insulated handles, burnished 160 mm
€54.41
-
TRONEX ESD side cutter 5113 oval head Cu 0.10-1.00 mm
€86.01
Total price
Over a full shift of cut after cut, the handle decides what the hand looks like in the evening. The 74 22 200 high leverage diagonal cutter cuts hard wire up to 3.0 mm and sits in comfort handles made of three ergonomic components, plus two KNIPEXtend interfaces.
Benefits
- Comfort handles made of three ergonomic components for optimised handling.
- Two KNIPEXtend interfaces accept extensions from the manufacturer system.
- Precision cutting edges additionally induction-hardened to approx. 64 HRC, for all wire types including piano wire up to 2.5 mm.
- High cutting performance with little effort due to the matched cutting edge angle and transmission ratio.
- Built for very tough, continuous use, 200 mm long at 300 g, manufactured to DIN ISO 5749.
Technical data
| EAN | 4003773051831 |
|---|---|
| Pliers | black atramentised |
| Head | polished |
| Handles | with comfort handles |
| Weight | 300 g |
| Dimensions | 200 x 53 x 24 mm |
| Standard | DIN ISO 5749 |
| REACH conformity | contains no SVHC |
| RoHS conformity | not applicable |
| Cutting capacity medium-hard wire (diameter) | Ø 4.2 mm |
| Cutting capacity hard wire (diameter) | Ø 3.0 mm |
| Cutting capacity piano wire (diameter) | Ø 2.5 mm |
Areas of use
Assembly, electrical and plant construction, maintenance and workshop, wherever many cuts follow one another and the tool has to sit well in the hand.
Standards and conformity
The tool is made to DIN ISO 5749. It is not insulated and therefore not intended for live working. According to the manufacturer it contains no substances of very high concern under REACH, the RoHS directive does not apply.
| Norm | DIN ISO 5749 |
|---|---|
| Manufacturer Nr. | 74 22 200 |
| Manufacturer | Knipex |
| EAN | 4003773051831 |
| Weight | 0.300000 |
| Colour | Black |
| Height | 24 mm |
| Width | 53 mm |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Article authenticity | Original product |
| Condition of article | New |
| Farbe | schwarz |
| Overall length [mm] | 200.000000 |
