Pliers wrench replaces a set of spanners, metric as well as imperial. Smooth jaws for gentle assembly of surface-finished fittings - work directly on chrome! Also excellent for gripping, holding, pressing and bending workpieces. No edge damage on sensitive fittings due to backlash-free, full-surface contact. Quick adjustment at the touch of a button directly on the workpiece. No unintentional adjustment of the gripper jaws and no slipping of the joint. Stepless gripping of all spanner sizes up to the specified capacity by means of parallel guided jaws. The stroke between the gripping jaws enables fast tightening and loosening of screw connections according to the ratchet principle. Increased gripping capacity due to two additional adjustment positions: stepless gripping of all wrench widths up to 40 mm. 10 % less weight with the same stability. Practical setting scale: A lasered scale allows the wrench width to be preset before gripping. with narrow gripping jaws - for screwing situations that require a slim tool. - jaw thickness (at joint) (B2): 8.0mm - joint thickness (B3): 12.0mm - point thickness (B1): 5.0mm - setting positions: 15 - capacity for nuts, width across flats (inches): 1 1/2 - capacity for nuts, width across flats (mm): 40mm
- Also excellent for gripping, holding, pressing and bending workpieces
- No edge damage to sensitive fittings due to backlash-free, full-surface contact
- Quick adjustment at the touch of a button directly on the workpiece
- No unintentional adjustment of the gripper jaws and no slipping of the joint
- Stepless gripping of all spanner sizes up to the specified capacity by means of parallel guided jaws
- The stroke between the gripping jaws allows quick tightening and loosening of screw connections according to the ratchet principle
Product details
| item number | WL61764 |
| model | 86 01 180 |
| manufacturer | KNIPEX |
| manufacturer item number | 86 01 180 |
| dimensions (LxWxH) | 183 mm x 46 mm x 15 mm |
| dimensions with packaging (LxWxH) | 192 mm x 61 mm x 20 mm |
| Packaging volume | 0.234 dm³ |
| order unit | piece |
| type of packaging | single pack |
| RoHS conform | no |
| surface | black atramentised |
| ESD safe | no |
| jaw thickness | 8 mm |
| VDE | no |
| tool length | 180 mm |
| description head | polished |
| type of handle | covered with plastic |
| type of pliers | pliers wrench |
