Other versions
| item number | tool length |
| WL61767 | 180 mm |
| WL61768 | 250 mm |
Pliers wrench replaces a set of spanners, metric as well as imperial. smooth jaws for gentle assembly of surface-finished fittings - work directly on chrome!. Also excellent for gripping, holding, pressing and bending workpieces. No edge damage on sensitive fittings due to backlash-free, full-surface contact. Quick adjustment at the touch of a button directly on the workpiece. No unintentional adjustment of the gripper jaws and no slipping of the joint. Stepless gripping of all spanner sizes up to the specified capacity by means of parallel guided jaws. The stroke between the gripping jaws allows fast tightening and loosening of screw connections according to the ratchet principle. - Jaw thickness (at joint) (B2): 8.0mm - Joint thickness (B3): 12.0mm - Tip thickness (B1): 5.0mm - Setting positions: 15 - Capacity for nuts, width across flats (inches): 1 1/2 - Capacity for nuts, width across flats (mm): 40mm
- Also excellent for gripping, holding, pressing and bending workpieces
- No edge damage on sensitive fittings due to backlash-free, full-surface contact
- Quick adjustment at the touch of a button directly on the workpiece
- No unintentional adjustment of the gripper jaws and no slipping of the joint
- Stepless gripping of all spanner sizes up to the specified capacity by means of parallel guided jaws
- The stroke between the gripping jaws allows quick tightening and loosening of screw connections according to the ratchet principle
Product details
| item number | WL61767 |
| model | 86 02 180 |
| manufacturer | KNIPEX |
| manufacturer item number | 86 02 180 |
| dimensions (LxWxH) | 187 mm x 56 mm x 20 mm |
| dimensions with packaging (LxWxH) | 190 mm x 60 mm x 20 mm |
| Packaging volume | 0.228 dm³ |
| order unit | piece |
| type of packaging | single pack |
| RoHS conform | no |
| surface | black atramentised |
| ESD safe | no |
| jaw thickness | 8 mm |
| VDE | no |
| tool length | 180 mm |
| description head | polished |
| type of handle | with multi-component sleeves |
| type of pliers | pliers wrench |
