Self-adjusting crimping pliers for ferrules with front loading, 190 mm, sales packaging - Knipex 97 53 08 SB

When wiring a control cabinet, every die change costs time and carries the risk of picking the wrong one. The self-adjusting crimping pliers 97 53 08 SB adapt automatically to the required ferrule size and crimp in a single profile. The ferrules are loaded into the tool from the front, it is 190 mm long and comes in a self-service blister.

Advantages

• Self-adjusting to the ferrule size, so no crimping errors from using the wrong die.
• Front loading of the ferrules into the tool, well suited to working at the end of a cable.
• Crimping to DIN 46228 part 1 and part 4 in a single profile, one tool covers the whole range.
• Consistently high crimping quality thanks to the ratchet, which can be unlocked, the crimping pressure is calibrated at the factory.
• High crimping force from the efficient lever action, high operating comfort from the handy shape and low weight.
• Ferrules up to 2.5 mm² can also be fed in parallel from the side.

SB version

SB stands for the self-service packaging. Tool and features match the standard version 97 53 08, the pliers are supplied ready for sale in a blister for shelf presentation.

Areas of use

Control cabinet building, electrical installation, machine and plant construction and maintenance. Wherever fine-stranded conductors are fitted with ferrules before connection and twin ferrules are used as well.

Standards and conformity

The pliers crimp ferrules to DIN 46228 part 1 and part 4. For the standard version the manufacturer also states a UL approved crimp in combination with the Knipex ferrules 97 99 330 to 97 99 399.
