Self-adjusting crimping pliers for wire ferrules with lateral access, square crimp up to 16 mm², 180 mm - Knipex 97 55 04 SB

Wiring a terminal row means changing cross-section constantly, and every die change costs time. These pliers set themselves to the required ferrule size automatically and crimp up to 16 mm² in a single die. The item is the self-service version of the 97 55 04 tool and is supplied in a retail pack.

Benefits

• Adjusts automatically to the required ferrule size for precise and quick crimping without changing dies.
• Ferrules are inserted from the side, so over-long ferrules can pass right through the tool.
• Square crimp, also suitable for all twin ferrules up to 2 x 6 mm² or 2 x AWG 10.
• Unlockable ratchet for repeatable crimping quality, the crimping pressure is calibrated at the factory.
• High crimping force from an efficient lever action, with a narrow handle width and low weight.
• Special quality chrome vanadium electric steel, oil-hardened, head and pliers chrome-plated.

Areas of use

Electrical installation, control cabinet and control system building, machine wiring and service work. The narrow handle width and the low weight pay off wherever crimping goes on by hand for longer periods. The retail pack is intended for sale from a display wall, the tool matches the 97 55 04 version.

Standards and conformity

Ferrules are crimped in line with DIN 46228 parts 1 + 4. In conjunction with KNIPEX wire ferrules 97 99 330 to 399 the crimp carries UL approval. Separate REACH and RoHS data are not available for this retail pack version.
