Cable connectors eye type, insulated, screw diameter 3 mm, red, 200 pieces - Knipex 97 99 170

Screw terminals and studs need a cable lug that stays in place even when the screw is loosened. These insulated cable connectors of the eye type to DIN 46237 are made for a screw diameter of 3 mm and come in a pack of 200 pieces with the colour code red.

Advantages

• Closed ring shape, so the connection cannot slip sideways off a loosened screw.
• Insulating collar covers the crimp barrel and protects the strand against kinking at the transition.
• Nylon insulation for use from -55 °C to +105 °C and a load of up to 600 V.
• Made to DIN 46237, so ring and crimp barrel match common crimping tools.
• Colour code red, the cross section range is recognised at once in the assortment.
• Pack of 200 pieces, enough for a complete terminal strip.

Technical data

Applications

The cable lugs are used in control cabinet and plant construction, on terminal strips, busbars and device connections as well as in vehicle and maintenance workshops. The stripped conductor is crimped with a tool for insulated connectors, then the ring is placed over the screw and tightened.

Standards and conformity

The cable lugs comply with DIN 46237 for insulated cable connectors. They contain no substances of very high concern under REACH. The RoHS directive is not applicable to this product.
