LED ring light natural white 4000 K, working distance 35 mm, max. clamping diameter 40 mm - Starlight RL40-35 NW
LED ring light in natural white (4000 K) for microscopy and inspection. Working distance 35 mm, clamping diameter up to 40 mm, 8 LEDs for low-shadow incident light.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The RL40-35 NW LED ring light delivers homogeneous natural white light (4000 K) and mounts directly onto the lens. With an optimal working distance of 35 mm it produces a low-shadow, high-contrast image for microscopy and inspection.
Benefits
- Homogeneous natural white light (4000 K) for high-contrast viewing
- Optimal working distance of 35 mm for comfortable handling under the lens
- Fits lenses up to a clamping diameter of 40 mm
- Robust housing of anodised aluminium, only 25.1 mm high
Applications
Ideal for incident-light microscopy, optical incoming and final inspection, electronics manufacturing, soldering and rework stations as well as laboratory and quality control.
Technical data
| Model | RL40-35 NW |
|---|---|
| Light colour | natural white (4000 K) |
| Working distance (optimal) | 35 mm |
| Max. clamping diameter | 40 mm |
| Inner diameter | 30 mm |
| Outer diameter | 58 mm |
| Inner thread | M30.5 x 0.5 |
| Number of LEDs | 8 |
| Power consumption | 6 W |
| Height | 25.1 mm |
| Material | anodised aluminium |
| Cable length | 1.4 m |
| Manufacturer part no. | 100-012231 |
| ESD safe | No |
| Weight | 0.1 kg |
| Manufacturer | Starlight |
| Manufacturer Nr. | 100-012231 |
| GPSR manufacturer information | STARLIGHT Opto-Electronics Flachslander Straße 8 DE-90431 Nürnberg www.starlight-sl.de |
| Condition of article | New |
| Article authenticity | Original product |
| Colour | White |
| Power (W) | 6 W |
