Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
LED ring light RL12 with 12 LEDs in warm white (3000 K) light colour and a working distance from 45 mm to 260 mm (optimum 100 mm). It illuminates the object area around the optics with low shadowing. M67 x 0.75 internal thread and 15 W power draw at 24V.
LED Ring Light 24V warm white (3000 K), working distance 45 mm - 260 mm - Starlight RL12-25s-24V WW
STARLIGHT Original product
Net price (excl. VAT)
€659.12
Item STL-100-010772
Manufacturer no. 100-010772
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.100-010772
ConditionNew
Article
STL-100-010772
Frequently Bought Together
- This Item: €659.12
- LED Ring Light UV/IR 395 nm, working distance 80 mm, clamp diameter max. 66 mm - Starlight RL66-80 UV395 €517.44
- LED Ring Light red 620 nm, inner Ø 81 mm, 56 LEDs - Starlight RL5-81-R €448.80
Total price
The RL12 LED ring light uses 12 LEDs in warm white (3000 K) to provide low-shadow ring illumination of the working area, covering a working distance from 45 mm to 260 mm (optimum 100 mm).
Benefits
- 12 LEDs in warm white (3000 K) light colour for even ring illumination
- Wide working distance from 45 mm to 260 mm, optimum at 100 mm
- M67 x 0.75 internal thread for direct mounting on common optics
- Compact 42 mm height at only 15 W power draw
- Anodised aluminium housing for rugged continuous operation
Technical data
| Model | RL12-25s-24V WW |
| Manufacturer | Starlight |
| Manufacturer part no. | 100-010772 |
| Light colour | warm white (3000 K) |
| Number of LEDs | 12 |
| Operating voltage | 24V |
| Power consumption | 15 W |
| Working distance | 45 mm - 260 mm |
| Optimum working distance | 100 mm |
| Inner diameter | 66 mm |
| Outer diameter | 130 mm |
| Height | 42 mm |
| Internal thread | M67 x 0.75 |
| Material | Anodised aluminium |
| ESD safe | no |
Applications
Ideal for microscopy, inspection, assembly, electronics rework and quality control where low-shadow ring illumination of the object area is required.
| Manufacturer Nr. | 100-010772 |
|---|---|
| Manufacturer | Starlight |
| Weight | 0.100000 |
| Colour | White |
| GPSR manufacturer information | STARLIGHT Opto-Electronics Flachslander Straße 8 DE-90431 Nürnberg www.starlight-sl.de |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
