ESD tweezers with interchangeable tips straight, blunt 2 mm tip, premium stainless steel, 130 mm - Knipex 92 81 01
ESD tweezers with replaceable carbon fibre reinforced plastic tips, surface resistance 10^2 to 10^4 ohms in line with DIN EN 61340-5-1. Straight design with blunt tips 0.4 mm (A) and 2 mm (B) wide for gripping sensitive parts across a surface. Premium stainless steel body, 130 mm long, 17 g.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Sensitive components can only be picked up without scratches if the tip is softer than the workpiece. The 92 81 01 works with blunt interchangeable tips 2 mm wide made of carbon fibre reinforced plastic, with a surface resistance between 10^2 and 10^4 ohms.
Benefits
- Blunt interchangeable tips 0.4 mm (A) and 2 mm (B) wide in a straight design, the component is held across a surface instead of at a point.
- Interchangeable tips made of 30 percent carbon fibre reinforced plastic, very good electrical and thermal conductivity, scratch resistant and highly resistant to abrasion.
- Surface resistance of the tips between 10^2 and 10^4 ohms, so differences in potential between operator and component are equalised in a controlled way. The manufacturer cites DIN EN 61340-5-1.
- Tips permanently temperature stable up to 130 °C and up to 190 °C for short periods, fully elastic, fatigue resistant, vibration damping and water repellent.
- Handcrafted body in premium stainless steel with polished edges and a matt, scratch-free and non-reflective surface, excellent resistance to most chemicals, salts and acids.
- Backlash-free three-point connection of two fixing points on the arms and one screw, worn tips are replaced individually instead of the whole tool.
Areas of use
Handling sensitive electronic components, micro-mechanical parts as well as glass and ceramic components. The manufacturer names the electronics and precision engineering industries, watchmakers and jewellers, and assigns this model to the industrial sector. The tips offer good chemical resistance to most oils, greases, fuels and non-polar solvents.
Standards and conformity
DIN EN 61340-5-1 is listed as the standard, ESD tested is marked yes and the electrical behaviour is stated as dissipative. VDE tested is marked no. According to the manufacturer the tweezers contain no substances of very high concern under REACH, and the RoHS directive does not apply.
Technical data
| EAN | 4003773087090 |
|---|---|
| Material | Premium stainless steel |
| Gripping surfaces | smooth gripping surfaces |
| Handles | Smooth |
| Weight | 17 g |
| Dimensions | 130 x 10 x 17 mm |
| Standard | DIN EN 61340-5-1 |
| REACH conformity | contains no SVHC |
| RoHS conformity | not applicable |
| Surface | Matt |
| Design | Straight |
| Tip width (A) | 0.4 mm |
| Tip width (B) | 2 mm |
| Tip design | Blunt |
| Corrosion-resistant | yes |
| Acid resistance | Very good |
| ESD tested | yes |
| VDE tested | no |
| Industries | Industry |
| Magnetic | Not magnetisable (80%) |
| Electrical behaviour | Dissipative |
| Manufacturer | Knipex |
| Manufacturer Nr. | 92 81 01 |
| GPSR manufacturer information | KNIPEX-Werk Oberkamper Strasse 13 DE-42349 Wuppertal-Cronenberg www.knipex.de |
| Condition of article | New |
| Article authenticity | Original product |
| Height | 17 mm |
| Width | 10 mm |
| Colour | Stainless Steel |
| ESD version | ESD (antistatic) |
| Norm | DIN EN 61340-5-1 |
| Overall length [mm] | 130.000000 |
