The product may differ from the illustration
Round chamfered soldering tip from the JBC R245 series, Ø 1 x 2 mm at a 40 degree angle and 11.5 mm length. With integrated heater for soldering through-hole pins and cables on the HA245 unit.
Soldering tip R245 round chamfered Ø 1 mm 40 degrees - JBC R245015
JBC
Original product
Net price (excl. VAT)
€33.20
Excl. 19% VAT ,
excl. Shipping Cost
Available
Fast shipping
Item
WL69823
Manufacturer no.
R245015
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R245015
Country of originSpain
Customs tariff number85159080900
ConditionNew
Article
WL69823
Frequently Bought Together
-
This Item:
€33.20Excl. 19% VAT , excl. Shipping Cost
-
JBC R470035. Soldering tip R470, chisel, 6x2 mm, R470035
€50.30Excl. 19% VAT , excl. Shipping Cost
-
JBC CLMR-A. Automatic soldering tip cleaning device
€553.30Excl. 19% VAT , excl. Shipping Cost
Total price
The JBC R245015 is a round chamfered soldering tip (cartridge) from the R245 series with an integrated heater for the TR245 and TRA245 automated soldering irons. The tip chamfered at 40 degrees offers a larger contact area for pin joints and cables, while the built-in heater delivers stable thermal performance.
Benefits
- Round chamfered tip Ø 1 x 2 mm for pin joints and cables
- 40 degree tip angle for an enlarged contact area
- Integrated heater for short heat-up time and stable temperature
- Tip length 11.5 mm, outer diameter 4.5 mm
- Directly compatible with the TR245 and TRA245 handpieces
Technical data
| Model | R245015 |
| Item no. | WL69823 |
| Manufacturer item no. | R245015 |
| Tip series | R245 |
| Tip shape | round, chamfered |
| Tip dimensions | Ø 1 x 2 mm |
| Tip diameter | 1 mm |
| Tip thickness | 2 mm |
| Tip length | 11.5 mm |
| Outer diameter | 4.5 mm |
| Tip angle | 40 degrees |
| Integrated heater | yes |
| Tip alignment | straight |
| Compatible soldering unit | HA245 |
| Suitable handpiece | TR245, TRA245 |
| Suitable stand | CS2R245 |
| Order unit | piece |
Applications
Soldering of through-hole pins and cables in automated electronics production on JBC R245 soldering irons.
Compatibility and scope of delivery
Supplied as a single soldering tip. Compatible with the TR245 and TRA245 soldering irons and the HA245 soldering unit. Matching stand: CS2R245.
ESD-safe per IEC 61340-5-1. Made by JBC, country of origin Spain.
| Execution | ESD (antistatic) |
|---|---|
| Manufacturer Nr. | R245015 |
| Manufacturer | JBC |
| Country of Manufacture | Spain |
| Weight | 0.100000 |
| HS-Code | 85159080900 |
| GPSR manufacturer information | JBC Soldering SL, Ramón y Cajal 3, ES-08750 Molins De Rei, www.jbctools.com |
| Article authenticity | Original product |
| Condition of article | New |
| Serie | R245 |
