Micro desoldering tip chisel 1.3 x 0.4 mm RTWMS 013 S for WTMT and WXMTS - Weller T0050116299

The micro desoldering tip RTWMS 013 S handles component removal with two heated tips. It works with 80 W at 12 V, is ready after 5 seconds and covers a control range of 100 to 450 °C. The geometry is chisel and straight with a tip width of 1.3 mm.

Benefits

• 80 W total power at 12 V, so the tip reaches the set temperature between 100 and 450 °C within 5 seconds
• Chisel geometry, straight, tip length 19 mm, tip width 1.3 mm, tip thickness 0.4 mm, tip diameter 2.8 mm, suited to resistors, capacitors and small SOT packages
• Tip change through the Active Tip Cartridge System without tools and without cooling the tweezers down
• Pre-aligned pairs remove realignment after a change, and an Allen key of 1.5 mm allows ±80° rotation and ±1.2 mm vertical adjustment when needed
• Tip identification with stored ID number, tip offset and tip lock for traceability and fixed process parameters
• Short distance between tip and handle plus a parallel sliding block guide for precise positioning on the component

Technical data

Applications

Rework and repair in electronics manufacturing, in the lab and in the test area. The tip shape suits resistors, capacitors and small SOT packages. The property table does not list the tip as ESD safe.

Compatibility and scope of delivery

The matching handpieces are the WTMT and WXMTS desoldering tweezers. The change runs through the Active Tip Cartridge System and needs no extra tool. Sales unit is 1 piece, the packaging measures 98 x 36 x 27 mm.

Standards and compliance

The series is Mil-Spec compliant and meets the IPC test method IPC TM-650 2.5.33 for measuring electrical overstress from soldering hand tools.
