Mantis ERGO eyepiece-less stereo microscope 3x to 15x with Verso universal stand - Vision SMR200

The Mantis ERGO covers 3x to 15x and changes magnification with a three position objective changer on the head. Viewing is eyepiece-less, which leaves enough distance to work on the part with tools while the dynamic 3D illumination puts structure onto the surface.

Key points

• Magnification 3x to 15x with a three position objective changer, three steps are ready without conversion.
• Dynamic 3D illumination lifts structure, scratches and solder joints into relief.
• Eyepiece-less viewing, head and neck stay upright and glasses are no obstacle.
• Verso universal stand with 230 mm working height and 380 to 505 mm reach, objects up to 166 mm tall fit underneath.
• White and UV illumination is available as an option, for instance to check conformal coating.
• The stereo head MRH001 ships without objectives, so the magnification is ordered to suit the task.

Stand

The Verso universal stand adjusts in height and its 380 to 505 mm reach swings the head over larger assemblies as well. This is the setup for objects that do not fit a compact bench stand.

Technical data

Applications

Inspection and rework in electronics manufacturing, assembly checks in medical technology, mechatronics, aerospace and automotive, plus laboratory work in the life sciences.

Compatibility and scope of delivery

The delivery covers the MANTIS ERGO stereo inspection microscope with Verso universal stand, stereo head MRH001 without objectives with LED illumination, Verso arm MTB200, dust cover MTA360 and power supply MTA330. Objectives are not part of it and are chosen by the magnification required. Weight, overall dimensions, EAN and customs code are not stated in the supplier data, and the property table does not list the system as ESD safe.
