Precision hand wire stripper for AWG 16, Ø 1.2 mm, for PVC and PTFE insulated wires - A1-ESD SWS-1200-AWG16
Compact hand stripper for AWG 16 wires with a 1.2 mm cutting diameter. Induction-hardened steel blades remove PVC and PTFE insulation cleanly without nicking the conductor. The graduated length stop gives repeatable strip lengths in production and repair.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
When wires are prepared in series, every cut needs the same length and an undamaged conductor. The SWS-1200-AWG16 is matched to AWG 16: its 1.2 mm cutting diameter suits wires from 1.09 to 1.19 mm, and the face bore accepts cables up to 2.2 mm outside diameter.
Benefits in use
- 1.2 mm cutting diameter matched to AWG 16, so the blade separates the insulation without damaging the conductor.
- Induction-hardened steel blades stay sharp and cut precisely even with frequent use.
- Graduated, adjustable length stop for identical strip lengths.
- Suitable for PVC and PTFE insulation and similarly insulated wires.
- Compact design that sits well in the hand and stays within reach at the bench.
Applications
Cable assembly, electronics production, prototyping, service and repair, wherever AWG 16 wires with PVC or PTFE insulation are stripped repeatedly to the same length.
Technical data
| Tool type | Hand wire stripper |
|---|---|
| Wire size | AWG 16 |
| Cutting diameter | 1.2 mm |
| Wire diameter | 1.09 to 1.19 mm |
| Max. cable outside diameter, face bore | 2.2 mm |
| Insulation | PVC, PTFE and similarly insulated wires |
| Length stop | graduated, adjustable |
| Blades | induction-hardened steel |
| ESD safe | no |
| Sales unit | 1 piece |
| Weight | 0.1 kg |
| Manufacturer | A1-ESD |
| Manufacturer Nr. | MDS-1200 |
| HS-Code | 82055980 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
Scope of delivery
One SWS-1200-AWG16 hand wire stripper.
