ESD SMD reel rack V11-8, for reels up to Ø 180 mm, horizontal storage, dissipative - Licefa 2426684

Small 7-inch reels tend to pile up loosely around the placement line. The Licefa V11-8 reel rack holds SMD reels up to Ø 180 mm stacked horizontally and takes up only 186 x 173 mm of bench space. With 190 mm of usable internal height the order is kept: reels are taken out first in / first out. The black polystyrene sits in the dissipative range of 10^4 to 10^11 ohms and is suitable for use in an EPA according to DIN EN 61340-5-1.

Benefits

• Takes SMD reels up to Ø 180 mm, usable interior 182 x 169 x 190 mm
• Horizontal first in / first out storage, older reels are used up first
• Smallest footprint of the horizontal V11 range: 186 x 173 mm, ideal at the feeder set-up station
• Dissipative PS at 10^4 to 10^11 ohms drains charges in a controlled way
• Weighs only 0.26 kg and moves easily between workstations
• Made in Germany

Applications

• SMT placement and feeder set-up for 7-inch reels
• Electronics production with small batch sizes
• Laboratory and prototyping
• Repair and service with changing component reels
