ESD SMD reel rack V11-9, for reels up to Ø 330 mm, horizontal storage, dissipative - Licefa 2426687

Large tape reels up to Ø 330 mm need a holder where they lie flat, do not jam and come out in the order they arrived. The Licefa V11-9 reel rack offers an interior of 335 x 315 mm with 190 mm of usable height. Reels are removed first in / first out, which helps to respect floor life limits of moisture sensitive devices. The black dissipative polystyrene with 10^4 to 10^11 ohms is designed for the EPA according to DIN EN 61340-5-1.

Benefits

• Takes 13-inch reels up to Ø 330 mm, usable interior 335 x 315 x 190 mm
• Horizontal first in / first out storage keeps the order of goods receipt
• Same 210 mm height as the V11-8 but roughly three times the base area for large reels
• Dissipative PS at 10^4 to 10^11 ohms for use inside the EPA
• At 0.52 kg light enough to move between stores and line
• Made in Germany

Applications

• SMT placement with 13-inch reels
• Goods receipt and buffer storage for taped components
• Picking of set-up kits for the line
• Storage of sensitive components in electronics production
