8767 B VDE HF TORX Zyklop bit socket TX 45, insulated, 3/8" drive, with holding function - Wera 05004925001

The largest tip size in the range: the 8767 B VDE HF Zyklop bit socket TX 45 fastens large TORX screws on live parts up to 1,000 V. At 59 mm overall length it stays compact, and the holding function keeps the screw securely on the tool while feeding it to the workpiece.

Benefits

• Individually tested at 10,000 V as per IEC 60900 for safe working up to 1,000 V
• 2-component insulation: the yellow insulation core under the red outer layer makes any damage visible at once
• HF holding function: the surface pressure between tip and screw profile clamps the TORX screw on the tool
• Particularly useful in hard-to-reach areas where the second hand is not free
• Plastic sleeve protects surfaces from damage

Applications

Switchgear construction, work on busbars and heavy connections, and maintenance of electrical systems with TORX screws under voltage up to 1,000 V. Fits Zyklop ratchets and accessories with 3/8" square drive.

Standards and safety

Insulated tool according to IEC 60900, every piece tested at 10,000 V and approved for a voltage of 1,000 V.
