LED arm-mounted luminaire TANEO TND 1400/940/D, 23 W, 1400 lm, 4000 K, white opal screen - Waldmann 113735000-00809728

At assembly, inspection and laboratory workstations the lighting decides how reliably details are recognised. The TANEO TND 1400/940/D provides 1400 lm at 23 W power consumption and is positioned precisely above the workpiece with its spring-relieved arm and 3D head joint.

What the luminaire delivers at the workplace

• 1400 lm luminous flux at 23 W power consumption, the 398 mm luminaire head covers a wide working area.
• Light color 4000 K neutral white with color rendering Ra above 90 keeps color differences and contrasts on the workpiece visible.
• The white opal screen creates a homogeneous light emission surface without visible screen structure, which helps on reflecting surfaces.
• Continuous dimming via the membrane switch in the luminaire head, plus a spring-relieved arm with 3D head joint and a large radius of action.
• Maintenance-free LED technology with up to 60,000 hours of service life, no lamp replacement required.
• Closed design in colorless anodised aluminium and fibreglass-reinforced plastic, degree of protection IP20, protection class III.
• 20-year Waldmann manufacturer's warranty, including LED light source and driver (Waldmann general warranty terms, purchase in the EEA)

Areas of application

• inspection workplaces with mirroring or reflecting surfaces
• laboratory and dental workstations
• jewellery, watchmaking and goldsmith work
• assembly and quality assurance

Mounting and accessories

The luminaire is fixed to the workplace by its arm, alternatively a space-saving substructure mounting is possible. This variant is mounted with its 16 mm pin in a socket or in a table clamp. Waldmann offers table clamps for panel thicknesses from 0 to 165 mm, an ESD table clamp and a black wall bracket as accessories.

Made by Herbert Waldmann GmbH und Co. KG in Villingen-Schwenningen, Germany.
