LED arm-mounted luminaire TANEO TND 1400/940/D, 23 W, 1500 lm, 4000 K, CDP screen - Waldmann 113735000-00809724

At assembly, inspection and laboratory workstations the lighting decides how reliably details are recognised. The TANEO TND 1400/940/D provides 1500 lm at 23 W power consumption and is positioned precisely above the workpiece with its spring-relieved arm and 3D head joint.

What the luminaire delivers at the workplace

• 1500 lm luminous flux at 23 W power consumption and 65 lm/W efficacy, the 398 mm luminaire head covers a wide working area.
• Light color 4000 K neutral white with color rendering Ra above 90 keeps color differences and contrasts on the workpiece visible.
• The CDP cone prism screen bundles the light and controls glare, which raises the usable light output at the workplace.
• Continuous dimming via the membrane switch in the luminaire head, plus a spring-relieved arm with 3D head joint and a large radius of action.
• Maintenance-free LED technology with up to 60,000 hours of service life, no lamp replacement required.
• Closed design in colorless anodised aluminium and fibreglass-reinforced plastic, degree of protection IP20, protection class III.

Areas of application

• assembly and manufacturing with changing part sizes
• quality assurance and visual inspection
• laboratory and analysis workstations
• electronics, metal, textile and watch industries

Mounting and accessories

The luminaire is fixed to the workplace by its arm, alternatively a space-saving substructure mounting is possible. This variant is mounted with its 16 mm pin in a socket or in a table clamp. Waldmann offers table clamps for panel thicknesses from 0 to 165 mm, an ESD table clamp and a black wall bracket as accessories.

Made by Herbert Waldmann GmbH und Co. KG in Villingen-Schwenningen, Germany.
