LED system luminaire TAMETO SAHQ 44 RD, 599 mm, 18 W, dimmable - Waldmann 113035000-00577614

Anyone building system workstations to a grid needs the luminaire in an exact length. The integrated TAMETO SAHQ 44 RD measures 599 mm, delivers 1500 lm at 18 W power consumption and can be dimmed continuously to the level the visual task requires.

What the luminaire delivers

• 1500 lm from 18 W, that is 83 lm/W, with continuous dimming down to the actual demand.
• The length of 599 mm fits system workstations on a 600 grid, the light is emitted over the full length without dark zones.
• Through-wiring via the built-in Wieland GST18i3 plug and socket links several luminaires to one supply cable.
• Colour rendering Ra > 90 and a UGR class of 22 or lower to DIN EN 12464-1 reduce eye strain during long inspection work.
• The PMMA conical prismatic cover controls glare of the direct symmetrical light distribution with a direct component of about 100 %.
• Maintenance-free LED with over 60,000 hours of service life in an enclosed aluminium housing, protection class IP20.

Areas of use

• Linked assembly lines with several workstations
• Test and measuring benches in electronics manufacturing
• System workstations in mechanics, laboratory and precision engineering
• Restorer and inspection workplaces with high demands on colour rendering
