LED workplace system luminaire TAMETO SAHQ 44 RD, 18 W, 1500 lm, 4000 K, continuously dimmable, through-wired - Waldmann 112972000-00555580

At a system workstation the light has to cover the whole table width, not just the centre. The TAMETO SAHQ 44 RD puts 1500 lm onto the surface over 656 mm of luminaire length and draws 18 W while doing so. Light is emitted along the entire length, so assembly, inspection and repair tasks are lit evenly.

What the luminaire delivers at the workplace

• Colour rendering Ra > 90 and flicker-free light, colour codes and fine details stay readable throughout the shift.
• The conical prismatic cover (CDP) controls glare across the full luminaire length of 656 mm, leaving no dark zones on the work surface.
• 1500 lm at 18 W power consumption, compared with luminaires using compact fluorescent lamps up to 40 % more illuminance and up to 60 % energy savings are possible.
• LED with a service life of over 60,000 hours, operation stays maintenance-free and without lamp changes.
• Continuously dimmable by push-button, brightness can be matched to the visual task and to the individual employee.
• Through-wired via Wieland GST 18i3, several luminaires in a row can be interlinked electrically.

Technical data

Areas of use

• Assembly workplace
• Watchmaker workplace
• Testing workplace
• Laboratory and dental workplace
• Restorer workplace

Scope of delivery and mounting

The luminaire is supplied with a 0.3 m connection cable with plug and socket Wieland GST 18i3. It is mounted with mounting brackets or via the two integrated T-slots (8 mm) on the rear, which keeps the connection to the table system flexible. The symmetrical profile leaves the choice of operating side open, and the cable is led out unobtrusively at the side.

Degree of protection IP20 and protection class I as stated by the manufacturer. Housing of colourless anodised aluminium and black plastic, cover of PMMA. Manufactured by Herbert Waldmann GmbH & Co. KG, Peter-Henlein-Strasse 5, 78056 Villingen-Schwenningen, Germany.
