Through-hole drag soldering tip, C245 series - JBC C245701
Datasheet (PDF)
The product may differ from the illustration
Special through-hole soldering tip of the C245 series for drag soldering of through holes. Suited to through-hole component soldering and high heat-demand applications such as soldering base plates.

Through-hole drag soldering tip, C245 series - JBC C245701

JBC Original product
Net price (excl. VAT)
€54.06
Excl. 19% VAT , excl. Shipping Cost
Available Fast shipping
Item WL84058
Manufacturer no. C245701
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.C245701
Country of originSpain
Customs tariff number85159080900
ConditionNew
Add to Wish List Add to Compare
Article
WL84058

For efficient drag soldering of through-hole joints, this pass-through tip carries solder continuously along the through holes. It suits through-hole component soldering and heat-intensive applications such as soldering base plates.

Benefits

  • Pass-through geometry for drag soldering rows of through holes
  • Suited to applications with high heat demand
  • Chisel-shaped, straight tip from the proven C245 series
  • JBC Long Life Tip with instant heat-up and long service life

Technical data

Article numberC245701
Tip seriesC245
Tip shapechisel
Tip orientationstraight
Applicationdrag soldering through holes
Length110 mm
Width12 mm
Height12 mm
Sales unit1 piece

Applications

Through-hole soldering of THT components, drag soldering of hole rows and soldering of base plates.

Compatibility and scope of delivery

Part of the C245 cartridge range for the JBC T245 general-purpose handle. Supplied as 1 piece.

Made in Spain.

More Information
Manufacturer Nr. C245701
Manufacturer JBC
Country of Manufacture Spain
Weight 0.100000
HS-Code 85159080900
GPSR manufacturer information JBC Soldering SL Ramón y Cajal 3 ES-08750 Molins De Rei www.jbctools.com
Article authenticity Original product
Condition of article New
Serie C245
