ESD workstation mat Infinity Bubble, round studs, 900 x 1200 mm, without snap

Operators who stand for hours at an ESD workstation need a surface that drains charge in a controlled way and takes load off the legs. This foamed polyurethane mat combines a 14.5 mm round-stud profile with a dissipation resistance of 3 x 10E7 to 5 x 10E7 Ohm. At 900 x 1200 mm the mat gives room to move along longer workbenches where the operator shifts sideways between tasks. This version has no snap. It suits sites where grounding is provided by a dissipative floor or by other means.

Benefits

• Round studs and 14.5 mm thickness cushion standing and relieve feet and back
• Closed-pore glossy surface, UV and chemical resistant, can be wet-cleaned, for dry and damp areas
• Fire-retardant to Cfl-s1 (B), silicone and latex free
• Suitable for cleanrooms to ISO class 6 (class 100)
• No snap, for areas where grounding is already in place

Applications

The 900 x 1200 mm format suits longer assembly and test benches in electronics production and cleanroom workstations where the operator does not stay in one spot. The mat supports setting up an EPA to IEC 61340-5-1. The surface tolerates wet cleaning, so it can also be used in areas exposed to moisture or cleaning agents. Available in further formats.
