ESD tapered head relief cutter 7223, flat, without bevel - Tronex 7223
ESD tapered head relief cutter 7223, flat, without bevel for electronics production and rework. Cuts soft copper wire from 0.1 mm - 0.9 mm / 38-19 AWG, edges hardened to 62-63 HRC. Overall length 142 mm, ESD-safe grips.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The ESD tapered head relief cutter 7223, flat, without bevel is an ESD-safe precision tool for electronics production. It handles soft copper wire in the range 0.1 mm - 0.9 mm / 38-19 AWG, with cutting edges hardened to 62-63 HRC. Head shape: Tapered head cutter.
Application: high cutting power for general cutting work in areas that are hard to reach.
Benefits
- Cutting edge: Without bevel
- Cutting capacity 0.1 mm - 0.9 mm / 38-19 AWG (soft copper wire)
- Tool steel hardened to 62-63 HRC
- ESD-safe double-dipped cushion grips, RTT resistance Below 1 x 10E11 ohm, tested to ANSI/ESD STM11.13 two-point probe
- Overall length 142 mm
Applications
Assembly and rework of electronic assemblies in the EPA, trimming component leads and fine wires, work under the microscope.
Technical data
| Brand | Tronex |
|---|---|
| Head style | Tapered head cutter |
| Profile | Relief |
| Material | Carbon steel |
| Material hardness | 62-63 HRC |
| Cutting edge | Without bevel |
| Cutting capacity (soft copper wire) | 0.1 mm - 0.9 mm / 38-19 AWG |
| Handle length | Long, ergonomic |
| Overall length | 142 mm |
| Handles | Dual-moulded cushion grips, ESD-safe |
| RTT resistance | Below 1 x 10E11 ohm, tested to ANSI/ESD STM11.13 two-point probe |
| Manufacturer part number | 7223 |
| Weight | 0.09 kg |
| Manufacturer | Tronex |
| Manufacturer Nr. | 7223 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| ESD version | ESD (antistatic) |
