Rectangular hood DN75, 420 x 320 mm, polypropylene, red flange - Alsident 1-754232-7-4

Name: Rectangular hood DN75, 420 x 320 mm, polypropylene, red flange - Alsident 1-754232-7-4
Brand: Alsident
SKU: AL-1-754232-7-4
Price: 149.10 EUR
Availability: InStock

Alsident ✓ Original product Brand new Made in Denmark

Chemical-resistant 420 x 320 mm rectangular hood in PP with red flange for the Alsident System 75 PP. The wide face captures vapours above large tanks, and the red flange marks the extraction point.

Net

€149.10

excl. VAT

Item AL-1-754232-7-4

Manufacturer no. 1-754232-7-4

Question about this item

Datasheet (PDF) 3 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Large rinsing and dip tanks release vapours across their full width. The Alsident hood 1-754232-7-4 captures them with a 420 x 320 mm face, placed angled above or upright behind the tank, with 92 % capture efficiency still at 350 mm in manufacturer tests. Hood, flange and stub are made of chemical-resistant PP, the flange is red.

Benefits

Red flange marks the extraction point
420 x 320 mm face for wide sources
Chemical-resistant PP for light and heavy gases
Reinforced edge for stable handling

Specifications

Applications

Dip and rinsing tanks in surface treatment
Solvent cleaning stations in maintenance
Dental laboratories working with monomers

Compatibility and scope of delivery

For Alsident System 75 PP extraction arms with 75 mm pipe diameter
With white flange: 1-754232-7-5
Scope of delivery: hood with stub pipe

Technical data

Manufacturer part no.	1-754232-7-4
Type	Rectangular hood
System	Alsident System 75 chemical resistant (PP)
Pipe diameter	75 mm
Hood size	420 x 320 mm
Material	Hood, flange and stub pipe in chemical-resistant polypropylene (PP)
Colour	red flange
Capture efficiency (manufacturer test, position A)	100 % at 200 mm, 92 % at 350 mm, 77 % at 500 mm distance
ESD-safe	no
Sales unit	1 piece
Weight	0.436 kg
Manufacturer	Alsident
Manufacturer Nr.	1-754232-7-4
HS-Code	84149000
GPSR manufacturer information	Alsident system A/S Finlandsvej 10 DK-8450 Hammel www.alsident.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Denmark
Compatible with	Alsident System 75
