ESD extraction arm DN100, 3 joints, 2130 mm, conductive PP, black, table mounting, ATEX - Alsident 100-10585-1-6

In electronics EPAs and in potentially explosive zones, no charge may build up on the extraction arm. The Alsident extraction arm 100-10585-1-6 therefore has tubes, joints, flanges and O-rings in conductive PP, reaches 2130 mm and handles 140 to 400 m³/h. It is approved to EN 80079-36:2016 and EN 80079-37:2016 and marked Ex II 1 GD.

Benefits

• Conductive PP throughout, suitable for ESD and ATEX areas
• Fixed earth lead for Ex areas plus a separate earth lead with 1 MΩ resistor for ESD areas
• 2130 mm reach and up to 400 m³/h for large workstations
• Two external gas springs hold the arm in any position
• Dismantled without tools for cleaning

Specifications

Applications

• ESD-protected soldering and rework stations in electronics production
• Ex zones in the chemical and pharmaceutical industry
• Filling of flammable solvents in the lab
• Large workstations in EPAs

Compatibility and scope of delivery

• Part of the Alsident System 100 AS, combine with the antistatic System 100 hoods to keep conductivity continuous
• In ATEX areas the manufacturer recommends brackets in acid-resistant stainless steel (spark-free to EN 1127-1 clause 5.3)
• Scope of delivery: extraction arm with earth leads, hood and bracket sold separately
• Risk assessment of the complete installation is the operator's responsibility, earthing by an electrician with Ex experience is recommended
