Extraction arm DN100, 3 joints, 2,130 mm, aluminium, white, wall mounting - Alsident 100-10585-2-5

For emission points spread far apart, this wall arm provides 2,130 mm reach over 3 joints. Two external gas springs carry the weight and keep the arm easy to guide. The AL version, with anodised aluminium tubes and white polypropylene joints, is intended for applications without special demands on chemical resistance or conductivity. System 100 is designed for 140 to 400 m³/h with a Ø100 mm tube.

Benefits

• Tubes in anodised aluminium (10 µm coating), joints in impact resistant, chemical resistant polypropylene
• 2 external gas springs instead of an internal spring, so the long arm stays in any position
• Integrated damper that sits outside the airflow when open for maximum throughput
• Dismantled without tools for cleaning, maintenance-free polyethylene (PE) O-rings

Specifications

Applications

• Laboratories with larger amounts of vapours or dust
• Hospitals and clinical areas
• Schools, universities and teaching rooms
• Food and machinery industry

Compatibility and scope of delivery

• Part of Alsident System 100. Arm, hood and bracket are ordered separately
• Matching hoods: 1-10024-5 (Ø200), 1-10036-5 (Ø350), 1-10035-5 (Ø385), 1-10050-5 (Ø500), 1-1004228-5 (420 x 280 mm)
• Wall bracket 2-100-203 (white), -050 (black), -22 (stainless steel AISI 316L), with reducer for Ø125 mm duct connection
• Protective grid 5-18 against foreign objects being sucked in, available as accessory
