Extraction arm DN100, 3 joints, 2130 mm, polypropylene, chemical resistant, white, table mounting - Alsident 100-10585-1-7-5

Where strong acids, alkalis or solvents are handled at the lab bench, the vapours attack aluminium over time. The Alsident extraction arm 100-10585-1-7-5 therefore has tubes, joints and flanges in chemical-resistant PP. With 2130 mm reach, Ø100 mm and 140 to 400 m³/h, it captures larger quantities right at the source, and two external gas springs hold it in position.

Benefits

• Tubes and joints in chemical-resistant PP for aggressive environments
• Threaded rods and springs in acid-resistant stainless steel AISI 316L
• 2130 mm reach, the longest table version in System 100
• Up to 400 m³/h for larger vapour quantities
• Dismantled without tools, maintenance is cleaning as needed

Specifications

Applications

• Chemistry and analytical labs with strong acids and alkalis
• Pharmaceutical industry and pharmacy labs with solvents
• Universities and student practicals
• Bench-top electroplating and surface treatment

Compatibility and scope of delivery

• Part of the Alsident System 100 PP, combine with the chemical-resistant System 100 hoods
• Order hoods, table brackets, U-profile, base box and accessories separately
• Wall version with the same reach: 100-10585-3-7-5
