Extraction cabinet type 2, 117 m³/h, 635 x 480 x 350 mm, clear PETG, white corners - Alsident 25-604535-5

Many small capture tasks do not need an open workstation but an enclosed space with just enough opening for hands and arms. The work cabinet 25-604535-5 is built exactly that way: a large interior on 635 x 480 mm, 350 mm overall height and a 515 x 145 mm opening. The recommended air flow is 117 m³/h.

Benefits

• Thermoformed from clear PETG, toughened glass pane in the sloping front
• Low air flow of 117 m³/h thanks to the small opening
• White PP corners on the glass pane, matching white flanges and components
• Performance measured by the Danish Technological Institute

Specifications

Applications

• Grinding in dental labs and goldsmith workshops
• Manual cleaning of small parts
• Decanting small quantities in pharmacies

Compatibility and scope of delivery

• Connection via white polypropylene cabinet flange, Ø 50 to Ø 160 mm, ordered separately, max. Ø 100 mm on the top
• State the flange position when ordering: standard on top or to your drawing
